| Which used to for pig dehairing in pig slaughterhouse, main data as following | |
| Model | QE-P209-II |
| Rated voltage / phase / frequency | 380v / 3p / 50hz |
| Power | 7.5Kw+3Kw |
| Out size | 2700*1700*2080mm(L*W*H) |
| Capacity | 200pig per hour |
| Dehairing time | 40s |
| Loading weight | ≤300Kg |
| Dehair effective length | 2.4m |
| Dehairing rate | ≥96 |
| Bone broken rate | ≤2% |
| Axis qty | 1/2sets |
| Component and material | 1)-Hot galvanized or stainless steel main frame 2)-Hot galvanized or SS304 dehairing roller with rubber sheet 3)-Hot galvanized or stainless steel concave-grid plate 4)-Stainless steel raking 5)-2mm stainless steel plate shell 6)-Hydraulic pressure station 7)-Oil cylinder and hydraulic control system and soft pipe |
