| Which main used to collect stunned pig and convey for killing, main data as following | |
| Model | QE-P108-I |
| Rated voltage / phase / frequency | 380v / 3p / 50hz |
| Power | 1.5Kw |
| Chain pitch | 100mm |
| Out size | 5000*1870*850(L*W*H) |
| Component and material | 1)-Stainless square steel 50 X 30X2mm / 40X20X2mm main frame 2)-Stainless square steel 75X25X2.5mm convey plate 3)-Stainless steel plate 2mm blood collection tank 4)-Stainless steel sprockets, chains, drive shaft |
| Which used to collect dehaired pig carcass for hair trimming, main data as following | |
| Model | QE-P211 |
| Rated voltage / phase / frequency | 380v / 3p / 50hz |
| Power | 1.5Kw |
| Chain pitch | 100mm |
| Out size | 5000*1550*500(L*W*H) |
| Component and material | 1)-38*38*2mm stainless square steel support 2)-High-quality carbon steel sprockets, plate chain, drive shaft 3)-60*30*2mm stainless square steel convey plate 4)-Driving &tension device |
